Cap: Threaded.
Nominal voltage: 250 V AC.
Connectors: screw terminals for rigid or flexible cables with a cross-section of 0.50–2.50 mm².
Fastening: with M10x1 threaded hole.
Dimensions
Diameter: 1 - 3/4 inches (40 mm)
Height: 2-1/8 inches (54 mm)
Ring nut diameter: 2 - 3/16 inches (56 mm)
UL-listás: E190302
Please note that this double-socket Bakelite lamp connector has a built-in locking safety device that prevents it from being unscrewed after assembly. (This is for protection against electric shock.)
We ship all of our lamp sockets.
not fully assembled and screwed together.
so that the built-in locking safety mechanism is not "locked" when you receive it.
If the safety device does lock for some reason, you can open this safety system with a small screwdriver located on the side of the socket. Please see our tutorial page for videos on how to open light bulb sockets. If you try to open the socket, the power supply will be interrupted.
to the socket before inserting anything into the socket!
